Morphology control is essentially about making and placing very small particles in their working position. Albeit somewhat a simplified description, as miniaturization becomes micro miniaturization and now molecule, crystal and sometimes even atom placement, the process engineering efforts are getting very challenging indeed. The efforts have been ongoing for decades. These are basic problems that sometimes simply stop great ideas from getting to market.
Until now a lack of morphology control of the active layer made it challenging to develop organic solar cells (OSCs) with large active areas.
OSCs, which use organic polymers to convert sunlight into electricity, have received considerable attention in recent times for their desirable properties as next-generation energy sources. These include lightweight, flexibility, scalability, and a high power conversion efficiency (>19%). Currently, several strategies exist for enhancing the performance and stability of OSCs. However, a problem that lingers on is the difficulty of controlling the morphology of the active layer in OSCs when scaling up to large areas. This makes it challenging to obtain high-quality active layer thin films and, in turn, fine-tune the device efficiency.
In a recent study, a team of researchers from the Gwangju Institute of Science and Technology, Korea set out to address this issue. In their work, published in Advanced Functional Materials, they suggested a solution that appears rather counterintuitive at first glance: using water treatment to control the active layer morphology.
Professor Dong-Yu Kim, who headed the study explained, “Water is known to hinder the performance of organic electronic devices, since it remains in the ‘trap states’ of the organic material, blocking the charge flow and degrading the device performance. However, we figured that using water rather than an organic solvent-based active solution as a medium of treatment method would enable necessary physical changes without causing chemical reactions.”
The researchers chose the polymers PTB7-Th and PM6 as donor materials and PC61BM and EH-IDTBR and Y6 as acceptor materials for the active layer.
They noticed that inducing a vortex to mix the donor and acceptor materials in the active solution could lead to a well-mixed active solution, yet it was not enough on its own. The active solution was hydrophobic and, accordingly, the researchers decided to use deionized (DI) water and vortices to stir the solution.
They let the donor and acceptor materials sit in chlorobenzene (host active solution) overnight, and then added DI water in the solution and stirred it, creating tiny vortices.
Due to the hydrophobic nature of the solution, the water pushed on the donor and acceptor molecules, causing them to dissolve more finely into the solution. They then let the solution rest, which caused the water to separate from the solution.
This water was then removed and the water-treated active solution was used to prepare thin films of PTB7-Th: PC61BM (F, fullerene), PTB7-Th: EH-IDTBR (NF, fullerene), and PM6: Y6 (H-NF, high-efficiency non-fullerene).
The researchers then examined the photovoltaic performance of these thin films in a slot-die-coated inverted OSC configuration and compared them with those for OSCs without water treatment.
Prof Kim noted, “We observed that the water-treated active solution led to a more uniform active layer thin films, which showed higher power conversion efficiencies compared to those not treated with water. Moreover, we fabricated large-area OSC modules with an active area of 10 cm2, which showed a conversion efficiency as high as 11.92% for water-treated H-NF films.”
Overall, this study provides a guideline for developing large-scale, efficient OSCs using a remarkably easy, economical, and eco-friendly method, which can open doors to their realization and commercialization.
***
In case you were wondering where the large organic solar cells were, this post shows what has been and what might be coming. This process has produced OSCs to better than ½ of the efficiency potential and they wouldn’t cost a small fortune.
ADVERTISEMENT
This post is an opportunity to show those who wonder “what happened to that great idea?” that comes up for a lot of what we see on these pages. This work from Korea is quite newsworthy, welcome and shows great innovation in a perplexing problem.
Everyone keep in mind there are thousands more perplexing problems out there. One could say engineering is making things with the systems and tooling that exist to get certain functions underway. Things to come to a stop if the systems simply haven’t been discovered yet.
By Brian Westenhaus via New Energy And Fuel
